100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic

100MM Downspout Roll Forming Machine

Round Downspout Roll Forming Machine

Automatic Downspout Roll Forming Machine

Nguồn gốc:

TRUNG QUỐC

Hàng hiệu:

CANGZHOU FMS

Chứng nhận:

ISO CE

Số mô hình:

Máy tạo cuộn ống xuống

Liên hệ với chúng tôi
Yêu cầu báo giá
Chi tiết sản phẩm
Tên sản phẩm:
Máy tạo hình cuộn tròn bằng thép màu 100 MM Kim loại tự động
Năng lực sản xuất:
13-15 m/phút
Cân nặng:
6850 kg
Chiều rộng cho ăn:
500mm
Kích thước (L * W * H):
7,5 * 1,65 * 1,5m
Sức mạnh chính của máy:
5,5kw
Điện áp:
380V 50Hz 3 pha hoặc theo yêu cầu
Tự động hóa:
hoàn toàn tự động
độ dày cán:
0,4-0,8 mm
Làm nổi bật:

100MM Downspout Roll Forming Machine

,

Round Downspout Roll Forming Machine

,

Automatic Downspout Roll Forming Machine

Điều khoản thanh toán và vận chuyển
Số lượng đặt hàng tối thiểu
1 bộ
Giá bán
negotiable
chi tiết đóng gói
FLC 20'
Thời gian giao hàng
30 ngày làm việc
Điều khoản thanh toán
L/c, t/t, d/a, d/p
Khả năng cung cấp
20 bộ mỗi tháng
Mô tả sản phẩm

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic ​


100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic Work Flow
    Decoiler→Manual Pre-Cutter→Guide Feeding →Roll Forming System→Hydraulic Post Cutter →Exit Rack



Downspout roll forming machine, known as rainwater downpipe roll forming machine as well, has been designed for making square or round (circle or rectangular) rainwater pipes. downspout has many different names as, waterspout, downpipe, drain spout, and roof drain pipe etc

Our downspout roll forming machine is special for manufacturing various size round downspout and rectangular downspout pipe.Downspout (Down pipe) is a pipe for conveying rain water from a roof or gutter to the ground or to a drain., also referred to as Leaderpipe, Downpipe, or Drainspout. The downspouts are more and more widely applied in rain water storage solution.


Specification

Tile Type
Colored Steel
Use
ROOF
Dimension(L*W*H)
7.5*1.65*1.5m
Weight
6850kg
Warranty
2 years
Key Selling Points
High Productivity
Rolling thinckness
0.4-0.8 mm
Warranty of core components
1.5 years
Core Components
Motor, Bearing, PLC
Product name
Downspout Roll Forming Machine
Color
Client's Request
Cutting blade material
Cr12 Quenched
Control system
Fully Automatic Computer Control




Installation


   During the installation and adjustment of the equipment, our engineers shall provide the training to the buyer’s personal request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation, and non-standard safety items, testing material and etc.



Guarantee



  The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during the guarantee period, we will provide the parts free of charge, which is in the conditions of correct operation. (Natural disasters or factors which can’t be forced by human are excluded).



Payment terms



  40% in advance

  60% is paid before shipping

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic 0
