Metal Roofing Downpipe Roll Forming Machine Rainwater Downspout

Metal Roofing Downpipe Roll Forming Machine Rainwater Downspout

PLC Downpipe Roll Forming Machine

10m/min Downpipe Roll Forming Machine

15m/min Downpipe Forming Machine

Nguồn gốc:

TRUNG QUỐC

Hàng hiệu:

CANGZHOU FMS

Chứng nhận:

ISO CE

Số mô hình:

Vòi vuông/vòng xuống

Liên hệ với chúng tôi
Yêu cầu báo giá
Chi tiết sản phẩm
Tên sản phẩm:
Tấm lợp kim loại Máy làm ống dẫn nước Máy tạo hình cuộn Ống thoát nước mưa
Năng lực sản xuất:
10-15m/phút
Cân nặng:
6500kg
độ dày:
0,3-0,8 mm
Hệ thống điều khiển:
PLC
Chiều rộng cho ăn:
1220mm
Điện áp:
380V 50Hz 3 pha hoặc theo yêu cầu của bạn
Làm nổi bật:

PLC Downpipe Roll Forming Machine

,

10m/min Downpipe Roll Forming Machine

,

15m/min Downpipe Forming Machine

Điều khoản thanh toán và vận chuyển
Số lượng đặt hàng tối thiểu
1 bộ
Giá bán
negotiable
chi tiết đóng gói
FLC 20'
Thời gian giao hàng
30 ngày làm việc
Điều khoản thanh toán
L/c, t/t, d/a, d/p
Khả năng cung cấp
20 bộ mỗi tháng
Mô tả sản phẩm

Metal Roofing Downpipe Making Machinery Roll Forming Machine Rainwater Downspout



   Metal Roofing Downpipe Making Machinery Roll Forming Machine Rainwater Downspout Advantage of steel :
Galvanized steel guttering resists thermal expansiono and contraction,which means that it remains unaffected from sudden fluctuations in temperature.Steel has an excellent lifetime value,as it can be recycled.
The downpipe forming machine we produced is customized according to the specific requirements of customers.Such as specification and raw materials, The machine is intalled and tested before leaving the factory.
After receiving the machine, the customer can start production once connect wires and tubes.We randomly send instructions to tell how to operate. Of course, we also have corresponding videos for reference.
Technicians Can also be sent to customer factory for guidance and training if necessary.
The downpipe roll forming machine also work with elbow bending machine,

which make flat pipe to curve according to construction requirement.



Specification



No. Item Description
1 Coil PPGI
2 Loading weight 3T
3 Thickness of Material 0.4-0.6mm
4 Roller Station 26 Stations
5

Dimension (L*W*H)

8000 mm*800 mm*1200 mm
6 Forming Speed 10-15m/min
7

Electrical Control System

PLC

8

Diameter of Shaft

¢70mm
9

Main Power

7.5KW
10

Power Supply

380V, 60HZ, 3 PHASES(can be customized)

11

Cutting Accuracy

± 2 mm

12

Hydraulic Power

7.5KW

13

Material of cutter blade

Cr12 steel with quenched treatment



Installation


  During the installation and adjustment of the equipment, our engineers shall provide the training to the buyer’s personal request to operate and  maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation, and non-standard safety items, testing material and etc.



Guarantee



  The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during the guarantee period, we will provide the parts free of charge, which is in the conditions of correct operation. (Natural disasters or factors which can’t be forced by human are excluded).



Payment terms



  40% in advance

  60% is paid before shipping
