IBR 900 building Roof Tile Roll Forming Machine Long Span 7 Ribs High Capacity

IBR 900 building Roof Tile Roll Forming Machine Long Span 7 Ribs High Capacity

building roof tile roll forming machine

ibr roof tile roll forming machine

7 ribs tile roll forming machine

Nguồn gốc:

TRUNG QUỐC

Hàng hiệu:

cangzhou fms

Chứng nhận:

CE,ISO

Liên hệ với chúng tôi
Yêu cầu báo giá
Chi tiết sản phẩm
Tên sản phẩm:
Máy tạo hình cuộn mái dài 900 7 sườn Công suất cao
Độ dày cuộn dây:
0,3-0,8mm
Kích thước (L * W * H):
7500X1500X1910mm
Cân nặng:
6,5T
Tốc độ:
12m/phút
Điện áp:
380V 3 pha 50HZ
Làm nổi bật:

building roof tile roll forming machine

,

ibr roof tile roll forming machine

,

7 ribs tile roll forming machine

Điều khoản thanh toán và vận chuyển
Số lượng đặt hàng tối thiểu
1 bộ
Giá bán
negotiable
chi tiết đóng gói
Máy chính có màu khỏa thân, hộp điều khiển máy tính được đóng gói bằng nhựa.
Thời gian giao hàng
30 ngày
Điều khoản thanh toán
T/T, Liên minh phương Tây
Khả năng cung cấp
30 bộ mỗi tháng
Sản phẩm liên quan
Liên hệ với chúng tôi
86-317-2016816
Liên hệ ngay
Mô tả sản phẩm

High Capacity 900 Long Span Roof Roll Forming Machine 7 Ribs



High Capacity 900 Long Span Roof Roll Forming Machine 7 Ribs.It has become a household name in the South African building industry. The IBR's deep, broad flute design offers first-rate drainage abilities with ideal weight versus load/span characteristics. IBR can be factory Cranked, Curved and Bullnosed to various radii depending on customer's requirements.
Because of price pressure of the material used to manufacture, this product is getting thinner and harder requiring these IBR Rollforming machines to be specially designed to produce and ensure a good quality finished product. It can also be noted that the machines are often required to run 915mm material as well or even 1225mm wide coil.



No.

High Capacity 900 Long Span Roof Roll Forming Machine 7 Ribs



1
Suitable material
Color steel sheet ,galvanized steel sheet, aluminium sheet
2
Width of material
1000mm or as need
3
Thickness of material
0.3-0.8mm or as your needs
4
Working speed
10-20m/min
5
Electrical control system
PLC control system
6
Shaft diameter
80mm/85mm
7
Dimension
7500x1500x1910mm
8
Weight
About 7 T
9
Voltage
380V 3phase 50HZ or as the customer's requirements
10
Material of roller
High grade 45# forged steel plated with hard chrome plating
11
Material of cutting
Cr12 mould steel with quenched treatment
12
Working time
Can be 24 hours
13
Workers
1-2 only





IBR 900 building Roof Tile Roll Forming Machine Long Span 7 Ribs High Capacity 0
