Double Layer Roll Forming Machine PLC Control

Double Layer Roll Forming Machine PLC Control

galvalume double roll forming machine

plc control double roll forming machine

plc control custom roll former

Nguồn gốc:

TRUNG QUỐC

Hàng hiệu:

CANGZHOU FMS

Chứng nhận:

ISO CE

Liên hệ với chúng tôi
Yêu cầu báo giá
Chi tiết sản phẩm
Tên sản phẩm:
Máy tạo hình cuộn hai lớp Điều khiển PLC
Nguyên liệu thô:
Galvalume, mạ kẽm, PPGI, nhôm
Hệ thống điều khiển:
điều khiển PLC
Sử dụng:
Bảng điều khiển mái và tường
Kiểu:
Tự động
lưỡi cắt:
CR12MOV
Độ dày phù hợp:
0,3-0,8mm hoặc theo yêu cầu của bạn
Tốc độ sản xuất:
15-20m/phút
Làm nổi bật:

galvalume double roll forming machine

,

plc control double roll forming machine

,

plc control custom roll former

Điều khoản thanh toán và vận chuyển
Số lượng đặt hàng tối thiểu
1 bộ
Giá bán
negotiable
chi tiết đóng gói
FLC 40'
Thời gian giao hàng
30 ngày làm việc
Điều khoản thanh toán
L/c, t/t, d/a, d/p
Khả năng cung cấp
20 bộ mỗi tháng
Mô tả sản phẩm

 Double Layer Roll Forming Machine PLC Control




CANGZHOU FAMOUS INTERNATIONAL TRADING CO., LTD is a professional manufacturer designing and producing roll forming machines established in June 1995.

Products mainly include trapezoidal steel roof/wall panel machine, C&Z shape purline machine, high-way guardrail machine, sandwich panel production line, deck forming machine, C U L light keel machine, shutter slat door forming machine, cutting machine, downpipe machine, gutter machine, etc.


Specification

Name Roofing Sheet And Wall Panel Double Layer Roll Forming Machine PLC Control
Raw Material Material Aluminium PPGI PPGL GI GL
Width 914/925/1000/1200/1220/1250/1260mm
Thickness 0.3-0.8mm, customized
Power Required Power 380V 3Phase 50Hz, customized
Main Motor 5.5KW, Lichao, Shanghai/Siemens Brand
Cutting Motor 4.0KW, Lichao, Shanghai/Siemens Brand
Roll Forming Machine Support Frame 350H steel, 10mm
Forming Station 16/18/21 rows, exactly according to profile drawing
Structure 16mm
Shaft 45# high grade steel, 80mm, solid, with keyway
Roller 45# high grade steel with heat treatment, hard chrome plated
Chain 1.0inch
Bearing Standard
Speed 12-18m/min
Electric Components Delta / Siemens / Mitsubishi
Cutting Blade Cr12Mov, quenched 58°-62°
Operation Touch Screen
Dimension 9.5*1.6*1.5M
Weight 8.0T


Guarantee

  1.Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.
  2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation


Payment terms

40% in advance as down payment
60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.
